Black Box Double-Shielded CAT6 Patch Cables ensure the performance of your Gigabit Ethernet network in high-noise environments: They feature four individually shielded twisted pairs with foam insulation and foil tape and an overall tinned copper braid to ensure protection against EMI and RFI interference that can distort or destroy your data. Tested to CAT6 standard 250-MHz performance, these cables meet or exceed the industry specification, ensuring the transmission of your voice, data or audio/video signal.
They feature plugs with 50-micron gold-plated contacts for superior conductivity. These cables have connectors designed for an insertion and extraction life of 750 cycles, making for an ultra-reliable solution that you can count on to perform. They feature molded slimline boots that provide added strain relief, which means they’re perfect for high-density applications. Available in a variety of lengths and colors, Black Box’s line of shielded CAT6 cabling gives you the flexibility to build your install however you want.
Approvals RoHS, CE, UL/cUL Standards TIA/EIA-568-B.2-1 Category 6 Connector 1 RJ-45 Male Connector 2 RJ-45 Male Connector Plating 50u Cable Jacket Type CM PVC Cable Type Stranded Conductor Gauge 26 AWG Shielded
S/FTP
100% foil tape around each pair with 40% mesh braid Cable Construction— Aluminum/Mylar tape around each pair, foam insulation, tinned-copper braid, PVC (CM) jacket Snagless Connector No Frequency Up to 250 MHz Attenuation (Maximum) 39.4dB at 250MHz Impedance 100+/-15 ohms NEXT (Minimum) 38.3dB at 250MHz PS-NEXT (Minimum) 36.3dB at 250MHz Return Loss (Minimum) 15.3dB at 250MHz
